Multifinction Adjustable Light Source for fiber network installation, fiber network engineering acceptance and fiber network maintenance. Combined usage with Q5014 handheld optical power meter, it offers a quick and accurate testing solution on both SM and MM fibers. The Light Source provides 4 wavelengths.
Features
-
Wave ID information can be transmitted when used with Q5014 Optical Power Meter.
-
Tone generation, 270HZ,330HZ,1KHZ,2KHZ
-
Output power can be adjustable
-
Output power value is shown on LCD display
-
Intelligent backlight control (light intensity can be adjusted properly according to ambient light, which greatly reduced power consumption)
-
3xAA or AC adapter for power supply
-
Low battery indication
Package content: Q5015 Light Source, AC adaptor, User Manual, Carrying Case, Cotton Swabs
| Part Number |
Q5015 |
Operating Wavelength |
850/1300/1310/1550 |
| Fibre Type |
SM, MM |
Laser Type |
FP-LD |
| Output Power (dBm) |
-5 (± 0.5) |
Adjustable step size (dBm) |
< 0.5 |
| Modulation |
CW, 270, 330, 1k, 2k |
Fibre Port |
FC |
| Power Supply |
Alkaline Battery (3 AA 1.5V batteries) or 8.4V Adaptor |
Battery Operating Time |
45 h |
| Operating Temperature |
-10 ~ +60 °C |
Storage Temperature |
-25 ~ +70 °C |
| Dimensions |
175x90x45mm |
Weight |
260 g |
|
